Multi Cyclone Dust Collector

Multi Cyclone Dust Collector Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Against Delivery (CAD), Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
1000 Units Per Month

Delivery Time
1 Days

Main Domestic Market
Gujarat

About Multi Cyclone Dust Collector

A multi-cyclone dust collector isan industrial air filtration device that uses multiple, smaller cyclone separators in parallel to efficiently remove dust and particulate matter from gas streams. Dust-laden air is forced into these cyclones, where centrifugal force spins the particles to the outer walls, causing them to fall to a collection bin while the cleaned air exits. This system is highly efficient, especially for separating fine dust, and is used in applications like woodworking, metal grinding, and capturing fly ash from boilers.

How it works

Inlet:Dust-laden air enters the collector through an inlet.
Distribution:An inlet plenum distributes the air evenly among the multiple, smaller cyclone chambers.
Separation:Inside each chamber, the air spins rapidly, creating a strong centrifugal force. This force pushes heavier dust particles to the outer walls of the cyclone.
Collection:The dust particles fall to the bottom of the chamber and are collected in a separate bin.
Outlet:The cleaned, lighter air moves toward the center of the cyclone and exits through an outlet.

Key features and advantages

Multiple chambers:Using numerous small-diameter cyclones in parallel increases the total separation surface area, which boosts efficiency and capacity compared to a single large cyclone.
High efficiency:The smaller diameter of the individual cyclones creates greater centrifugal force, leading to better separation of fine dust particles.
Dust handling:The system can effectively handle large volumes of dust-laden air, improving air quality and protecting equipment.
Application:It is a common and effective device for various industrial processes, including woodworking, metal grinding, and removing fly ash from boilers.
