Multi Cyclone Separator

Multi Cyclone Separator Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
1000 Units Per Month

Delivery Time
1 Days

Main Domestic Market
Gujarat

About Multi Cyclone Separator

A multi-cyclone separator isan air pollution control device that uses multiple smaller cyclones in parallel to efficiently remove particles from a gas stream through centrifugal force. It is more efficient than a single cyclone because the smaller diameter increases centrifugal force and the parallel arrangement allows for a longer residence time, leading to better separation of finer particles. These systems are common in industrial applications like boilers, acting as a pre-cleaner to protect more sensitive filters.

How it works

Dust-laden air enters:The gas stream with suspended particles enters a common inlet of the multi-cyclone unit.
Gas enters individual cyclones:The gas is then distributed to multiple smaller, parallel cyclone tubes.
Centrifugal force:Within each tube, the gas is forced into a spiral motion, creating a strong centrifugal force that pushes heavier particles against the outer wall.
Particle separation:The particles move along the wall and are collected in a hopper, while the now-cleaner gas exits through a common outlet at the top of the unit.

Key features and benefits

High efficiency:Achieves high collection efficiency, often over 99% for particles larger than 5 microns.
Pre-cleaning:It is frequently used as a pre-cleaner for other filtration systems like baghouses or ESPs, protecting them from abrasive large particles and extending their life.
High temperature and moisture tolerant:Can be built to handle high temperature and moisture conditions.
Simple design:Features no moving parts, which results in a simple construction, low maintenance, and low operational costs.
Higher pressure drop:The smaller diameter of the individual cyclones results in a higher pressure drop compared to a single large cyclone, but this is a trade-off for the higher efficiency achieved.
